Upload a structural steel PDF. FrameAI extracts every member, runs the Eurocode calculations, and outputs the full suite of fabrication-ready files.
Drop a structural steel drawing PDF. FrameAI reads the geometry, extracts every member, runs EN 1993 checks, and shows you the results — no account, no card, nothing kept.
Your PDF is processed in-memory and deleted within 60 seconds. No storage, no training.
Drop a structural PDF here
or
Upload the architect's PDF. That's it. No setup, no modeling.
FrameAI identifies every column, beam, brace, and connection — automatically.
In minutes, you have the full model — BBS schedules, connection details, panel schedules, IFC export.
EN 1993 and EN 1992 checks on every member and connection. Pass/fail, every time.
Fabrication-ready output — your shop floor and CNC machine can use it tomorrow.
Downloadable DSTV NC1, DXF, IFC, and PDF for each project.
Pick a sample below. Get back Eurocode checks and a BIM preview in seconds.
No file needed — pre-loaded sample data
The repetitive work — routing steel, numbering parts, generating shop drawings, running load calculations — it never ends. And there aren't enough experienced hands to go around.
FrameAI automates every engineering discipline. From your input specs to code-compliant fabrication drawings across structural, electrical, civil, and more. Every step. Every time.
Upload a PDF, DWG, or IFC. FrameAI parses dimensions, member sizes, grid lines, and connection types automatically. No manual entry.
Calculations run automatically: EN 1993-1-1 section class, EN 1993-1-8 bolted connections & fillet welds, and EN 1992-1-1 §6.1 RC beam bending design. Mixed steel–concrete frames in one run. View Eurocode validation report →
Shop drawings generated from the model — part marks, dimensions, weld symbols, and material specs ready for the workshop. IFC 4.0 CoordinationView 2.0 BIM export opens directly in Tekla Structures, Revit, Allplan, ArchiCAD, and Solibri — with Eurocode utilisation ratios embedded as property sets. Tekla round-trip guide →
Cross-discipline clashes flagged before they reach the workshop. Structural conflicts with architectural and MEP elements surfaced and ranked by severity.
Exact steel quantities extracted from the model — profiles, lengths, connection plates, fasteners. Ready for your estimating workflow or procurement system.
Watch the full pipeline run end-to-end on a real portal frame drawing — GPT-4o extraction, EN 1993 checks, fabrication PDF — no sign-up needed.
Upload your panel Excel. Get NEC Art. 220 demand calculations, cable sizing, voltage drop checks, and a submittal-ready PDF — in under 2 minutes.
Try Electrical Demo →From steel portal frames to reinforced concrete BBS to electrical panel schedules — FrameAI handles the full design-to-fabrication workflow. Pick your discipline.
Endplate moment, baseplate, beam splice, haunch stiffener. DSTV NC1 export for CNC machines.
BBS bar schedule, EC2 bending and shear checks, pad footing design. BS 8666 shape codes ready for the workshop.
Upload your circuit Excel. Get demand factors, cable sizing, voltage drop checks, and a submittal-ready PDF.
Extended endplate moment (A325/A490), column baseplate (F1554), beam splice — imperial-native, AISC DG-4 compliant.
Loop diagrams, I/O schedules, CCTV coverage analysis, access control specs. IEC 62443-3-3 SL-1 to SL-4, EN 54-14.
Upload any PDF drawing set — portal frame, RC frame, mixed use. FrameAI outputs a full IFC 4.0 CoordinationView 2.0 model.
SLD generation, IEEE 80 grounding grid, equipment specs, bus bar sizing for substations up to 400 kV.
Battery sizing, thermal runaway analysis, NFPA 855 compliance, IEEE 1547 interconnection for utility-scale and C&I BESS.
Drop a PDF, DWG, or IFC file — or just describe the structure in plain language. FrameAI parses everything.
FrameAI reconstructs the 3D model, runs Eurocode compliance checks, and flags clashes — all autonomously.
Fabrication drawings, calculation report, BOM, and IFC model — all ready to hand to the workshop or client.
Eurocode-compliant. Built for European structural workflows.
Ready to run today.
